Ductile Iron Manhole Cover and Grating | EN124:1994 | Material: GGG500-7 |
Class | Application | Dimension (Frame mm) |
A15 | Pedestrians, Pedal Cyclists | Dia760 |
B125 | Footways, Pedestrians, Car parks | 290*290, dia800 … |
C250 | Kerbside channel of roads | 700*700, 600*800 … |
D400 | Road, hard shoulders etc. | 850*850, 920*920 … |
E600 | Docks, aircraft pavements etc. | as per your demands |
F900 | Aircraft pavements etc. | as per your demands |
Size
|
Model
|
Pressure
|
Size
|
Model
|
Pressure
|
300*500
|
B125
|
15T
|
700*700
|
D400
|
50T
|
400*400
|
B125
|
15T
|
800*800
|
C250
|
25T
|
500*500
|
C250
|
25T
|
800*1200
|
D400
|
40T
|
500*1000
|
D400
|
50T
|
1000*1000
|
C250
|
25T
|
600*600
|
C250
|
25T
|
1000*1000
|
D400
|
40T
|
600*800
|
C250
|
25T
|
1200*1200
|
D125
|
15T
|
700*700
|
C250
|
25T
|
1200*1200
|
D400
|
30T
|
1. Anti-falling: A ductile iron net is designed for the well base to ensure the safety of citizens and children.
2. Anti-noise: A sealing rubber strip is designed between the well cover and the well seat, and a soft contact is formed between the cover and the seat, thereby eliminating noise.
3. Anti-deformation: The well base is designed with a 100mm surrounding structural pressure-bearing edge and a 190mm well-bore, so that the impact stress of the vehicle can be effectively diffused in multiple directions, greatly reducing the probability of settlement. , It is not easy to deform when driving and under heavy vehicles, and effectively solves the phenomenon of unevenness of the old manhole cover.
4. Anti-slip: The surface of the manhole cover has a dense pattern with convex and concave, and the height of the pattern reaches 3-8mm required by the national standard, which improves the coefficient of friction.
5. Anti-jumping: There are three buckles on the back of the manhole cover to fasten the locking device, and the well shaft corresponds to three buckle points. After the well cover is closed, the buckle point of the well-bore locks the buckle of the manhole cover, and the heavy-duty vehicle passes through to avoid bouncing.
6. Anti-theft: The well cover and the well seat are connected by 8.8-grade pin shaft screws. After installation, they are hidden underground. It is difficult to disassemble and not easy to steal.
Application:According to the bearing capacity of the product, anti-settling manhole covers can be used in the following places: municipal roads, highways, communications, electricity, tap water, residential areas, schools and other parks.
Remark:The company has complete and advanced production equipment and production technology, and can customize products of any size according to customers’ samples or drawings.
Q: Are you a manufacturer?
A: Yes, we are a manufacturer, we have our own factory. And we are the leading company in our county. We promise that we are exactly the reliable supplier you have been looking for.
Q:Can we visit your factory ?
A:Yes, of course, we welcome you to visit our factory to check our production lines and know more about our capacity, quality.
Q: Do you have quality control system?
A: Yes, we have ISO, BV, SGS certifications and our own quality control laboratory.
Q: Can you arrange the shipment for us?
A: Yes, Our freight forwarders are through the company tender, signed long-term agreement, Price Service is the best. we have designated sea-freight and railway freight Forwarders with decades of experiences and we can get the best price with earliest vessel and professional services.
Q: How long is your delivery time?
A: Generally it is 7-14 days if we have the exact goods in our stock. If not, it will take around 25-35 days to get goods ready
for delivery.
Q: How do you keep long-term business and good relationship ?
A: 1. We keep supplying good quality products and competitive prices to ensure our customers’ benefit.
2. We think highly of every single customers of us and value the relationship, we take it not only as business partner, but also as true friends. Will keep the good services and put customers’ benefit as high priority.
